CuZn37 (CW508L)
Grade : | CuZn37 |
Number: | CW508L |
Classification: | Copper-zinc alloy |
Chemical composition % of grade CuZn37 ( CW508L )
Fe | Ni | Al | Cu | Pb | Sn | Others | - |
max 0.1 | max 0.3 | max 0.05 | 62 - 64 | max 0.1 | max 0.1 | total 0.1 | Zn - remainder |
Mechanical properties of grade CuZn37 ( CW508L )
Rm - Tensile strength (MPa) (R300) | 300-370 |
Rm - Tensile strength (MPa) (R350) | 350-440 |
Rm - Tensile strength (MPa) (R410) | 410-490 |
Rp0.2 0.2% proof strength (MPa) (R300) | 180 |
Rp0.2 0.2% proof strength (MPa) (R350) | 170 |
Rp0.2 0.2% proof strength (MPa) (R410) | 300 |
A - Min. elongation at fracture (%) (R300) | 48 |
A - Min. elongation at fracture (%) (R350) | 28 |
A - Min. elongation at fracture (%) (R410) | 12 |
A - Min. elongation Lo = 50mm (%) (R300) | 38 |
A - Min. elongation Lo = 50mm (%) (R350) | 19 |
A - Min. elongation Lo = 50mm (%) (R410) | 8 |
Vickers hardness ( HV): (H055) | 55 - 95 |
Vickers hardness ( HV): (H095) | 95 - 125 |
Vickers hardness ( HV): (H120) | 120 - 155 |
